Brand Name : | Deshisen |
Model Number : | ZH1000-4A |
Certification : | CE |
Price : | CNY 147,000.00/SET |
Payment Terms : | T/T |
Supply Ability : | 20 SET 25Day |
Delivery Time : | 5-8 work day |
Model | ZH1000-4A | Working width | 1310MM |
material | ≥300g/m²cartons | Air compressor | min. 6 bar |
Minimum paper size | 250mm×250mm | total power | 18 KW (380V AC 3φ 50Hz) |
Maximum paper size | 1300mm×1050mm | weight | 1600KG |
The highest speed | 60m/min-100m/min | Machine dimensions | 6600*2100*1600 |
Feature:
1. The machine is running steady with strengthened driving system, and it is also easy for maintenance.
2. The motor is controlled by a transducer (inventer) which is available for automatic timing. It is power saved and helps to work stably.
3. An electric adjusting system in the machine makes it more conveniently when adjusting the space of carriers which usually based on the double-face tooth rods adjusting system.
4. Feeder is controlled by a separated motor. Paper is usually feed by several thick belts under the help of vibration motor. Feeding is continuous,exact and automatic with this system.
5. Grinders are provided in both sides of machine, to make gluing more stable and firm.
6. Two sets of gluing devices: gluing for bottom glue, gluing for side glue. All standard glue units shall apply thread glue. Space adjustment is made by means of toothed bars.
Safety performance:
A: Electrical safety meets the national standard (CE certification);
B: The exposed transmission parts are covered and marked; There is
an emergency stop button on the remote control, front end of
feeding, rear end of receiving and middle console.
C: In line with the national requirements for energy conservation
and emission reduction, the motor energy efficiency is level 2
D: Maintenance is convenient and quick. Butter is added to the glue
machine head and main drive shaft with a butter nozzle;
![]() |
